A low-profile mounting solution designed to convert MOLLE slots into secure, bolt-on attachment points.
This backing plate system sandwiches the MOLLE panel, allowing accessories to be mounted using a single bolt that threads directly into a heat-set insert. The integrated boss indexes into the MOLLE slot, preventing movement and maintaining precise alignment under load.
Designed specifically for standard 1.0" x 0.75" MOLLE slot openings, ensuring proper fit and engagement.
Unlike traditional MOLLE attachments that rely on straps or clips, this system provides a rigid, repeatable mounting interface suitable for hard-mounted accessories.
Key Features
-
Threaded Insert Core
Integrated heat-set insert provides durable, reusable threads for consistent clamping force. -
Boss-Locating Design
Raised boss fits into MOLLE slot to prevent shifting, rotation, and misalignment. -
Low-Profile Base
Compact footprint minimizes interference with adjacent slots and accessories. -
Rigid Mounting Interface
Transforms MOLLE into a stable platform for bolt-on accessories. -
Tool-Friendly Installation
Single-bolt design simplifies mounting and removal.
Thread Options
-
M5 Version
- Thread Size: M5
- Thread Depth: 8 mm
- Ideal for lighter accessories and compact mounts
- Ideal for Bravo Concealment Holsters
- 14mm length bolt, locking washer and washer recommended
-
M6 Version
- Thread Size: M6
- Thread Depth: 9 mm
- Ideal for heavier-duty applications and higher clamp force
- 14mm length bolt, locking washer and washer recommended
Applications
- HAM Radio mounts
- Small gear brackets
- Custom accessory interfaces
Material
- ASA (heat-resistant, UV-stable, suitable for vehicle interiors)
- Brass
Notes
- Designed for 1.0" x 0.75" MOLLE slot openings
- Requires compatible bolt (included)
- Select appropriate thread size based on application
- MOLLE Panel NOT included (for illustration purpose only)
A simple component that expands what MOLLE panels can support—turning soft mounting systems into precise, hard-mounted solutions.0
